Bonding Method
Injection molding
A method of bonding resin and surface-treated aluminum for bonding is employed at the same time as injection molding of the resin.
Thermocompression bonding
Only the resin at the aluminum-resin interface is melted by heat conduction from the aluminum, and a load is applied to bond the aluminum and resin.
Bondable metal and resin
| Metal | Surface treatment | Resin | |||||
|---|---|---|---|---|---|---|---|
| PA | PPS | PBT | ABS | PP | |||
| Aluminum | A5052 (Sheet material) | Laser treatment | 〇 | 〇 | 〇 | 〇 | 〇 |
| Wet treatment | 〇 | 〇 | 〇 | △ | × | ||
| A1050 (Sheet material) | Laser treatment | 〇 | 〇 | 〇 | 〇 | 〇 | |
| Wet treatment | 〇 | 〇 | 〇 | △ | × | ||
| A6063 (Extrusion material) | Laser treatment | 〇 | 〇 | 〇 | 〇 | 〇 | |
| Wet treatment | 〇 | 〇 | 〇 | △ | × | ||
| ADC12 | Laser treatment | 〇 | 〇 | 〇 | 〇 | 〇 | |
| Wet treatment | 〇 | 〇 | 〇 | △ | × | ||
| Copper | C1100 | Laser treatment | ー | 〇 | ー | ー | ー |
| Stainless steel | SUS304 | Laser treatment | ー | 〇 | ー | ー | ー |
○：Resin base material fracture △：Low bonding strength ×：Bonding not possible －：Not investigated
